Band saw grinding wheel
Electroplated CBN wire grinding wheel for grinding high alloy band saw
Electroplated CBN grinding wheels are commonly used for processing band saw brands, including
Wood-Mizer, Timberwolf, Simonds, Kasco, Morse, Lenox, Dakin Flathers/Ripper 37 and others
Different models, different processing
* 10/30 - Most commonly used all-purpose grinding wheel profile
* 9/29 - Prepares the bandsaw for winter cutting or cutting hard wood
* 13/29 - Wheel profile that prepares the bandsaw for cutting soft wood
* 4/32 - Wheel profile that prepares the bandsaw for very frozen and very hard wood cutting
* 7/34 CBN wheel profile recommended for hardwood
Drawing of CBN grinding wheel (electric wheel) for band saw blade
Outer diameter | Inner hole |
Inch | Millimeters | Inch | Millimeters |
5 | 127 | 1/ 2 | 12.7 |
6 | 150 | 25/32 | 20 |
8 | 203 | 1, 1 1/4 | 25.4, 32 |
| Special sizes can be produced according to band saw profiles. |
